Application
Electronic, Hardware, Machinery, Car
Transport Package
Cartons
Specification
Hardware, Spec Customized
| Parts Name |
Precision mould standard punch pin gauge for press die / Machine Tool / Precision CNC Machined Parts |
| Material |
SKH51, M2, 1.3343, HSS, SKD61, equivalent |
| Mounting Method |
Plastic injection mold |
| Polishing |
Can be close to Ra 0.4, standard is R0.8 |
| Hardness |
SKH51/M2/1.3343 (HRC 60-62); SKD61 (HRC 58-62) |
| Closest Tolerance |
Shaft: 0mm to -0.01mm; Head: 0mm to -0.05mm |
| Standards |
MISIMI / DIN / AISI / DANLY / DME / HASCO / TOHATSU / FIBRO / AGATHON / STRACK / PEDROTTI / RAYMOND / FUTABA / SANKYO / PROGRESSIVE / RABOURDIN etc |
Surface Coating: Improvement of mold part quality through professional PVD coating.
| Surface Coating |
Definition |
Feature |
Note |
| TiN (Titanium Nitride) |
Most economical and commonly used PVD wear resistant coating. |
Excellent wear resistance; superb lubrication; thermal stability. |
Recommended with lubricants; not for stainless steel/copper. |
| TiCN (Titanium Carbon Nitride) |
Suitable for stainless steel, nickel, and copper metals. |
Higher hardness and lower friction coefficient than TiN. |
Extremely high wear resistance; micro hardness up to 3,000 Vickers. |
| TiAlN (Titanium Aluminum Nitride) |
Generates aluminum oxide protection for heat-generating applications. |
High thermal stability; extra protection against shear stress. |
Micro hardness up to 3,400 Vickers. |
Packaging Details:
- ■ Soft foam to prevent surface scratches in small cardboard boxes.
- ■ Multiple small boxes packed in larger hard cardboards with fillers.
- ■ Product codes used on packaging to maintain confidentiality.
Shipping Methods:
- ■ International Express: UPS, TNT, DHL.
- ■ Port transportation to all major ports.
- ■ Insurance provided for goods according to contract.
01
Competitive Price: Calculated reasonably to support customers in market competition.
02
Consistent Quality Control: Experienced staff and QCs ensure 100% high-quality products with exact dimensions.
03
Quick Delivery Time: Optimized processes usually ensure a delivery time within 5 days.
04
Made-to-Order Service: Custom special parts available based on detailed customer requirements.
05
Excellent Support: Comprehensive pre-sales, in-sales, and after-sales services.
FAQ
Q1: What materials are available for the mold parts?
We use high-quality materials including SKH51, M2, 1.3343, HSS, and SKD61 or their equivalents to ensure durability and precision.
Q2: How do you ensure the precision of the dimensions?
Our parts are manufactured by experienced staff using advanced CNC turning, grinding, and milling. We can achieve tolerances as close as 0mm to -0.01mm for shafts.
Q3: Can I get customized surface coatings?
Yes, we provide TiN, TiCN, and TiAlN PVD coatings to improve wear resistance, lubrication, and thermal stability depending on your application needs.
Q4: Do you support international standards?
We manufacture according to various international standards including MISUMI, DIN, AISI, DANLY, DME, HASCO, FIBRO, and more.
Q5: What is your typical production capacity and lead time?
Our production capacity is approximately 50,000 units per month. Depending on the order quantity and complexity, we usually ensure a quick delivery time of around 5 days.
Q6: Is customized packaging available?
Yes, we can arrange packaging according to your special requirements. We also use neutral coding on cardboards to maintain deal confidentiality.
Thank you very much for reading. Welcome to contact with us!
We will provide you with the best service!
Xinli Technology
