To address the urgent demand for vaccine production, the upgraded technology of the prefilled syringes labeling system has enhanced performance stability. The S400 model plays a critical role in massive vaccine production cycles, ensuring high-speed efficiency and precision.
Range of Application
This equipment is sophisticatedly developed to connect with prefilled syringe systems. When integrated with an automatic nest-remover and syringe rod trimmer, it completes:
Needle tube nest-removing
Push rod feeding & combination booster
Combination torsion bar and outerwear labeling
High-speed syringe labeling
Buffer platform management
Equipped with top-ranking servo controls and Germany PLC, it ensures the rubber plug remains stable during assembly. Advanced visual detectors monitor if the push rod is correctly placed or adjusted.
Model Characteristics
Stable production capacity reaching 400bpm.
Tight tolerance range: 0.2~0.5ml between push rod and rubber plug.
Aviation-grade craftwork with sophisticated materials.
Versatile combination for standalone or connected operations.
Corresponding parts required for different diameters
3
Labeling Accuracy
±0.5mm
Excluding paste & label error
4
Label Sending Speed
≤60 meters/minute
-
5
Label Roll
Inner: 76mm, Outer: 350mm
-
6
Label Specs
(L)15-100 (W)10-80 mm
-
7
Power
220V±5% 50/60Hz 1KW
-
8
Machine Size
Approx. 2600 x 1000 x 1600 mm
Final plan to confirm exact dimensions
Frequently Asked Questions
Q1: What is the maximum production capacity of the S400 system?
A: The S400 is designed for high-volume production, reaching a stable capacity of up to 400 pieces per minute (400bpm).
Q2: Which syringe sizes are compatible with this equipment?
A: It supports a wide range of disposable syringes from 1ml to 10ml, with tube diameters between Ø6mm and Ø20mm.
Q3: How precise is the labeling process?
A: The system offers high-precision labeling with an accuracy tolerance of ±0.5mm, ensuring professional medical packaging standards.
Q4: Can the S400 handle the assembly of the plunger rod?
A: Yes, it synchronously performs needle nesting, pusher feeding, and screwing of the rod before the labeling process.
Q5: Does the machine include quality control features?
A: Yes, it is equipped with advanced intelligent visual detectors to ensure push rods are correctly seated and optional automatic rejection devices for non-compliant products.
Q6: What certifications does this machinery hold?
A: The equipment is fully compliant with international standards, holding CE, GMP, and ISO certifications.
